The 3:1 ratio Panther® pump is suitable for simultaneous fluid distribution of up to five dispense points, or for pumping to distances of up to 500 feet. The Panther's air motor features a precision air reversing valve mechanism with dual valve ports for improved high speed breathing. It also contains a positive trip detent spool mechanism that eliminates stalling (blowing air) when the pump is caught between strokes. The Panther® pumping assembly features a nitrided steel pump rod and foot valve for superior wear and corrosion resistance. The pump's exterior is constructed from aircraft grade extruded aluminum for an outstanding strength-to weight ratio. The pump also has high quality Buna-N seals and is packaged in a pump that has proven reliable yet easy to service and maintain.



Features

• Suitable for simultaneous fluid distribution of up to five dispense points, or for pumping to distances of up to 500 feet.
• Pump delivery with SAE 10W-30 oil, 68º F, 100 PSI air pressure and free flow - 8 gal/m (30 l/m).
• Air consumption (100 PSI and 4 G/M) 19.70 SCFM.
• Max fluid stall pressure @150 PSI air 490 PSI (33.8 bar).
• Wetted materials - Carbon steel, Buna-N™, stainless steel, nickel plated steel, nylon, ultrathane, zinc plated steel, and aluminum.
• 34 Cycles per Gal
• Effective air piston diameter 2.5" (63.5 mm)
• Air inlet - 1/4" NPT (F)
• Fluid inlet - 1" NPT (F), 1-1/2" NPT (M)
• Fluid outlet - 3/4" NPT (F)



Technical

Weight approx.	20	lbs
Power supply	Air	V/Hz/A
Dimensions (L x W x H)	23-1/2 H	inch



Options

44-1130-021	Panther 5:1 Pump with Bung Adapter - Oil	$789.00	Add to cart
44-4410-054	Panther Pump Hose Connecting Kit	$177.00	Add to cart
44-4411-008	Wall Mount Bracket for LYNX, Panther HP and Tiger pumps	$118.00	Add to cart



Accessories

44-3230-018	In-Line Hand Operated Valve for Air - 1/4" - 580 PSI	$13.00	Add to cart
44-3230-019	In-Line Hand Operated Valve for Air - 3/8" - 580 PSI	$17.00	Add to cart
44-3230-020	In-Line Hand Operated Valve for Air - 1/2" - 580 PSI	$18.00	Add to cart
44-3230-021	In-Line Hand Operated Valve for Air - 3/4" - 580 PSI	$23.00	Add to cart
44-3230-022	In-Line Hand Operated Valve for Air - 1" - 580 PSI	$36.00	Add to cart
44-4411-009N	Aluminum bung adapter w/pressure relief for Panther HP & Tiger pumps	$73.00	Add to cart
