The L Series oil-injected rotary screw compressors provide a range that combines high performance, low operating costs and reliability with ease of installation and servicing. Industries both large and small rely on Champion rotary screw compressors for a constant supply of high-quality compressed air. Specifications and Features: 30HP Pressure at 100 psig 125.8 CFM at 100 psig Fixed Speed Base Mounted 2-Year Warranty Factory Filled with CompLube 8000



Features

• Compact design, which gives you a small footprint.
• TEFC High Efficiency Motor.
• Quiet Enclosure to reduce sound levels.
• Wye/Delta Starter.
• Delcos Microprocessor based control system.
• Automatic belt tensioning system.



Technical

Dimensions (L x W x H)	31 x 28 x 47	inch
Weight approx.	810	lbs
Power supply	208-230, 460 / 60 / 3ph	V/Hz/A



Options

27-L22AC125TV	Champion 30HP, Rotary Screw Fixed Speed Compressor, 125 PSIG, 208-230/460/3/60	$17,905.00	Add to cart
27-L22AC125TVAS12	Champion 30HP AirStation, Rotary Screw Fixed Speed Compressor, 125 PSIG, 208-230/460/3/60, 120 Gallon Tank, With Dryer	$22,619.00	Add to cart
27-L22AC145TV	Champion 30HP, Rotary Screw Fixed Speed Compressor, 145 PSIG, 208-230/460/3/60	$17,905.00	Add to cart
27-L22AC190TV	Champion 30HP, Rotary Screw Fixed Speed Compressor, 190 PSIG, 208-230/460/3/60	$17,905.00	Add to cart



Accessories

27-28H369	CompLube 8000 advanced, synthetic lubricant for CompAir rotary screw compressors -- 2.5 Gallon	$554.00	Add to cart
27-28H388	CompLube 8000 advanced, synthetic lubricant for CompAir rotary screw compressors	$900.00	Add to cart
27-PA204-2161-1	CompAir L15-L22 Platinum Warranty Kit	$482.00	Add to cart
