Welding

CMI300 Trio Pulse MIG/MAG Package (includes 3 torches & 3 drive wheels)

200-CAR90573TRIOPK

EASY SWITCH-OVER WITH TRIO The CMI™300 Pulse is available in three versions: SINGLE, DUO and TRIO. The TRIO version with three 8” spools of wires, providing easy switch-over between operations without change of torch, wire, wire drive rolls and gas. The machine automatically detects which torch/wire feed unit is active.

MIG BRAZING

In addition to sheet metal welding, the CMI™300 Pulse features MIG brazing with and without the pulse of galvanized steel plates. MIG Brazing requires less heat, reducing distortion of thin plates, protecting heat-sensitive advanced high strength steels, and maintaining the corrosion resistance. The result is a time-saving, cost-effective, joining process required by multiple manufacturers.

CMI™300 PULSE WITH 36 PRE-SET PROGRAMS The programs meet the requirements for welding and brazing, for example for high-tensile steel and aluminum used by the automotive industry.

DOUBLE PULSE FOR WELDING AND BRAZING CMI™300 Pulse features double pulse – a function required by several OEMs that further controls the heat in the weld and provide a TIG-like appearance. Double pulse settings are fully adjustable.

BOOST FOR VERSATILE SUPPLY VOLTAGE The CMI™300 Pulse is available with a built-in Boost Converter (electronic autotransformer) for welding on single and three-phase mains voltages from 208V to 440V (50/60 Hz).

IGC® — FOR OPTIMAL SHIELDING OF WELD POOL IGC (Intelligent Gas Control)* ensures optimal shielding of the weld pool and maintains the strength in the joint. The result is large-scale gas savings, better arc ignition, and a minimum of weld spatter.

MIG-A TWIST® The ergonomic MIG-A Twist torch has a turnable swan neck that allows you to access hard-to-reach places. MIG-A Twist is available in different lengths. The optional remote unit allows the technician to adjust the settings right from the torch as they weld.

The CMI™300 Trio Pulse Boost MIG Welder is used for all welding applications, including aluminum, steels, and MIG brazing (silicone bronze) for high strength steel. The CMI300 Trio is equipped with a 4-wheel wire feeding system, which provides steady, reliable feed for aluminum wire.

All Car-O-Liner CMI™300 welders come with the 4 meter (13.5’) MIG-A Twist torch/welding guns, allowing technicians to reach hard to reach areas and has a maximum amperage of 300 Amps.

The welders can operate in single phase or three phase through automatic recognition and are extremely easy to use with presets for different materials and thickness. Turn it on, press the button, and weld!

The CMI300 Trio Pulse MIG/MAG package includes:

(1) CARNA90573 - CMI300 Trio Pulse Welder
(2) CARNA-90584 - ML240 Twist 4m 1.2mm Teflon-FE
(1) CARNA-90582 - ML240 Twist 4m 0.6-.08mm-FE
(1) CAR73940058 - Wire Feed Kit-1.2 mm–U-Red
(2) CAR73940054 - Wire Feed Kit-0.8 mm–V -White
(6) CAR80131200 - Contact Tip-0.8mm-M6 CuCrZ
(2) CAR80131202 - Contact Tip 1.2 M6 CuCrZr
(1) CARNA-90579 - Work Tray

Features

Trio Pulse ensures precise control of the arc and minimizes weld spatter.
Four-roll wire system for stable wire feeding.
Tachometer control of wire motor for ultra-precise feeding.
LED light in the wire console for easy change of wire and wire rolls in a low-light environment.
Soft-key control panel with color display and an intuitive icon-based menu.
Arc adjust function for precision adjustment between soft and hard arc.
Easy operation for inexperienced welders but fully adjustable for advanced technicians.
Software update via SD card.
Log for storage and display of welding data on an SD card, applicable for documentation of compliance with repair procedures.
